Construction

6 products

Cyclon ERGON CTP TO-4 10W - Construction Cyclon ERGON CTP TO-4 10W Specially formulated oil meeting Caterpillar TO-4 specification, delivering superior friction control, anti-wear protection, seal/metal… Cyclon ERGON CTP TO-4 30 - Construction Cyclon ERGON CTP TO-4 30 Specially formulated oil meeting Caterpillar TO-4 specification, delivering superior friction control, anti-wear protection, seal/metal… Cyclon ERGON CTP TO-4 50 - Construction Cyclon ERGON CTP TO-4 50 Specially formulated oil meeting Caterpillar TO-4 specification, delivering superior friction control, anti-wear protection, seal/metal… Cyclon ERGON MAXX 10W-40 - Construction Cyclon ERGON MAXX 10W-40 Advanced low-SAPS engine oil for modern construction and off-road machinery equipped with EGR, SCR… Cyclon ERGON SHPD 15W-40 - Construction Cyclon ERGON SHPD 15W-40 Mineral heavy-duty engine oil for construction, mining and mixed on/off-road equipment. Delivers reliable protection… Cyclon ERGON SHPD LS 15W-40 - Construction Cyclon ERGON SHPD LS 15W-40 Premium heavy-duty oil for severe-duty construction and mining engines. Offers outstanding wear protection, thermal…

Construction and mining: two different products, and one expensive mistake

The mistake: engine oil in a powershift transmission

This is the most costly error made on construction fleets, and it is made constantly because the drums look similar and one oil seems simpler than two. A powershift transmission, a wet brake and a final drive need an oil to Caterpillar TO-4 — not an engine oil. Engine oils contain friction modifiers designed to reduce friction, which is exactly wrong inside a clutch pack or a wet brake. The result is clutch slip, brake chatter, overheating and eventually a transmission rebuild.

ERGON CTP TO-4 is the correct product, in SAE 10W, 30 and 50. The machine's own compartment chart says which grade goes where — typically the lighter grade for hydraulics and cold-climate transmission duty, the middle grade for powershift transmissions, the heavy grade for final drives — and it should be read rather than guessed, because it varies by manufacturer and by machine.

Engine oil: after-treatment decides it

  • Older machines with no after-treatment — the bulk of plant working in Iraq. ERGON SHPD 15W-40 is the mineral heavy-duty oil for construction, mining and mixed on and off-road equipment, with reliable protection against wear, soot and deposits under heavy load. ERGON SHPD LS 15W-40 steps up for severe-duty engines, extended service intervals and units with after-treatment.
  • Modern machines with EGR, SCR or DPF — European Stage IV/V and EPA Tier 4. ERGON MAXX 10W-40 is the low-SAPS oil these need, with the oxidation control, shear stability and wear protection to handle severe duty without loading the filter with ash.

Hours, not kilometres

An excavator or loader has no odometer worth using. Service on engine hours, and shorten the manufacturer's interval where the site is dusty or the fuel is poor — both of which describe most Iraqi sites. A quarry loader accumulates more engine life in a month than a highway truck does in a quarter.

What actually kills machines here

In this climate the failure modes are predictable, and none of them are about oil brand:

  • Air filtration. Dust ingested past a damaged or badly seated filter wears an engine out faster than any oil can protect it. Check the seal, not just the element.
  • Hydraulic contamination. Dust and water entering the reservoir causes more pump failures than oil quality ever will. See the hydraulic oil guidance for the housekeeping that prevents it.
  • Grease points. Pins and bushes on excavators and loaders want a molybdenum disulphide grease and generous application, so fresh grease purges abrasive out of the joint. See the grease guidance.
  • Cooling. A radiator packed with dust in 50 °C ambient raises oil temperature across every compartment on the machine. Cleaning it is a lubrication decision as much as a cooling one.

Frequently asked questions

Can I use engine oil in a powershift transmission or final drive?

No, and this is the most expensive mistake made on construction fleets. Powershift transmissions, wet brakes and final drives need an oil meeting Caterpillar TO-4, such as Cyclon ERGON CTP TO-4 in SAE 10W, 30 or 50. Engine oils contain friction modifiers designed to reduce friction, which is exactly wrong inside a clutch pack or a wet brake, and the result is clutch slip, brake chatter, overheating and eventually a transmission rebuild. The machine's compartment chart says which TO-4 grade goes where, and it varies by manufacturer and machine, so it should be read rather than assumed.

Which engine oil for construction and mining equipment in Iraq?

For older machines without exhaust after-treatment, which is most plant working here, Cyclon ERGON SHPD 15W-40 covers construction, mining and mixed on and off-road duty, with ERGON SHPD LS 15W-40 for severe-duty engines and extended intervals. For modern machines with EGR, SCR or DPF systems meeting European Stage IV and V or EPA Tier 4, use the low-SAPS Cyclon ERGON MAXX 10W-40. A high-SAPS oil in a machine with a particulate filter loads the filter with ash that regeneration cannot remove.

How often should construction equipment oil be changed?

On engine hours, not kilometres, because an excavator or loader has no useful odometer. Take the manufacturer's hour figure and shorten it where the site is dusty or the fuel is poor, which describes most Iraqi sites. A quarry loader accumulates more engine life in a month than a highway truck does in a quarter.

What causes most equipment failures in Iraqi conditions?

Contamination rather than oil quality. Dust ingested past a damaged or badly seated air filter wears an engine out faster than any oil can protect it, so check the seal and not only the element. Dust and water entering a hydraulic reservoir cause more pump failures than oil choice ever will. Pins and bushes need a molybdenum disulphide grease applied generously so fresh grease purges abrasive from the joint. And a radiator packed with dust in 50 degree ambient raises oil temperature in every compartment on the machine, which makes cleaning it a lubrication decision as much as a cooling one.

Not sure which product a vehicle, machine or fleet needs? Try the Cyclon oil selector, or send us the details and we will specify it in writing.
